Product Description
DZ25 Numerical Control Drilling Machine adopts advanced intelligent PLC control platform. Its moving parts utilize the imported servo system. Screws and guide rail. The process can be programmed; inputting data into PLC system, positioning the drill bits and drilling automatically, suitable for processing of drilling more holes on glass with high precision.
Main Technical Specifications
- Diameter of hole: 4-100mm
- Glass thickness : 5-30mm
- Drilling position deviation: +0.50mm
- Max height of glass processing: 2500mm
- Min dimension of glass processing: 500x150mm
- Total power: 6.45KW
- Total weight: 2500Kg
- Overall dimension: 1700x1100x2000mm
